12V40kg-cm Hight Voltage BLS Swash Servo

12V40kg-cm Hight Voltage BLS Swash Servo

795,00 DKK

Vejl. udsalgspris 795,00 DKK

Model/Varenr.: RCKL-BLS8140H
Lagerstatus: 6 stk. på lager
stk.

1-1 Storage Temperature Range -20℃～70℃

1-2 Operating Temperature Range -15℃～65℃

2-1 Temperature range 25℃ ±5℃

2-2 Humidity range 65%±10%

3-1 Size 20*40*38 mm

3-2 Weight 78g no including accessory

3-3 Gear type Stainless Steel

3-6 Limit angle 210°

3-7 Bearing 2 Ball bearings

3-8 Horn gear spline 25T-φ5.96mm

3-9 Horn type Plastic,POM

3-10 Case Aluminium CNC

3-11 Connector wire 300mm 22AWG

3-12 Motor Brushless motor

3-13 waterproof Yes

7,4V

4-1 No load speed 0.11 sec/60°

4-2 Runnig current(at no load) 320 mA

4-3 Peak stall torque 25 kg.cm

4-4 Stall current 2.8 A

No. Operating Voltage Range 8.4 V     12 V

4-1 No load speed 0.094 sec/60°         0.07 sec/60°

4-2 Runnig current(at no load) 370 mA 440 mA

4-3 Peak stall torque             29 kg.cm 40 kg.cm

4-4 Stall current                       3.5 A       4.0 A



5-1 Command signal PWM

5-2 Amplifier type Digital Controller

5-3 Pulse width range 800～2200µsec

5-4 Neutral position 1520 µsec

5-5 Running degree 96°(when 1000～2000 µ sec)

5-6 Dead band width 1 µsec

5-7 Rotating direction CCW (when 1000～2000 µsec)
